ANTNX High Standard Quality Welder Portable Digital Aluminum Inverter MIG/CO2 Welding Machine 220V MIG-218G ANTNX.COM

ANTNX High Standard Quality Welder Portable Digital Aluminum Inverter MIG/CO2 Welding Machine 220V MIG-218G ANTNX.COM

$1,453.14 USD
$1,816.43 USD $1,453.14 USD
Sale Sold out
Shipping calculated at checkout.
Product Description

Main features:

Include IGBT inverter,soft switching control technology and fasy arc ignition system to ensure an efficient and steady welding,Material mechanical properties are maintained with less welding deformation and spatter,User can weld car bodies with various meterials and achieve the ultimate performance with minimum post welding treatment work quickly and easily.
1. SYNERGIC function-rapid and easy setting of welding programes.Ensures a constant strong control on the arc for the quality welding.
2. Applicarble on a wide range of materials such as steel,stainless steel,HSS high strength steels,galvanized sheets,aluminum and its alloys.
3. Suitable for soft wore such as the ALSI5 or AISI12(recommended for car body repairs)
4. With momory function,can store and recall 6 sets of customize welding data
5. Digital display panel and the latest PWM control technology.Double-pulse technology ideal for aluminum welding
Specification
Model
MIG-218G
MIG-218G mini
Input Power Voltage(VAC)
1PH.AC220V
1PH.AC220V
Rated Input Capacity(KVA)
5.3
5.3
Rated Input Current(A)
24
24
No-load Voltage(V)
65
65
Output Current Range(A)
10-160
10-160
Rated Duty Cycle(%)
60
60
Diameter Of Rod(mm)
Ø0.8 / Ø1.0 / Ø1.2
Ø0.8 / Ø1.0 / Ø1.2
Insulation Class
F
F
Protection Class
Ip21
Ip21
Efficiency(%)
85
85
Power Factor(cosφ)
0.93
0.93
N.W.(kg)
22.8
22.8
Dimensions(mm)
525*249*445
475*255*370
