ANTNX API Standard DTH Drill Rods Water Well Dth Drilling Pipe Price for Sale ANTNX.COM

ANTNX API Standard DTH Drill Rods Water Well Dth Drilling Pipe Price for Sale ANTNX.COM

$786.83 USD
$983.54 USD $786.83 USD
Sale Sold out
Shipping calculated at checkout.
Products Description

DTH Drill pipe

Drill pipes that are used in applications such as DTH/ DTHR/ DR basically comprise of a steel tube with a pin at one end and a box on the other. The job of the drill pipe is to transmit rotational torque and thrust from the drill rig rotary head to down hole drilling tools.
DTH drill tubes are used for connecting DTH hammer and DTH button bits; they are made from seamless tubes. Tubes play a significant role in all DTH drilling, regardless of application, rock type, hole depth or drill rig. The key features of a high quality DTH tube are durability, accuracy and manageability. According to different application, different diameters of drill tubes are needed, basically, smaller DTH hammers need smaller DTH drill tubes, vice avers. Usually we are offering 50mm, 60mm, 76mm, 89mm, etc. ALL DTH drill tubes are friction welded, and usually the threads are standard API connections,like23/8" API REG thread, 3 1/2" API REG thread or API IF thread, etc. According to customers request, from 1000mm to 5000mm length of tubes are available.
mm
mm
mm
mm
Joints connection
OD A
Wall thickness B
Effecitve length L
Wrench flat C/G
Pin-Box
76
5.5
1000/1500/2000
3000
57/65
2 3/8” REG
76
6.5
1000/1500/3000
4000/5000/6000
65
2 3/8” REG
89
5.5
1000/1500/2000
3000
65
2 3/8” REG, 2 3/8” IF
89
6.5
1000/1500/2000
3000/4500/6000
65
2 3/8” REG, 2 3/8” IF
102
6.5
1500/2000/3000
4000/5000/6000
75/83
2 7/8” REG
102
8.5
1500/2000/3000
4000/5000/6000
75/83
2 7/8” REG
114
6.5
1000/1500/2000
3000/4500/6000
89/95
3 1/2” REG, 2 7/8” IF, 3 1/2” IF
114
8.5
1500/2000/3000
4000/5000/6000
89/95
3 1/2” REG, 2 7/8” IF, 3 1/2” IF
127
10
3000/4000/5000
6000/8100/9140
89
3 1/2” REG, 4 1/2” REG,
127
19
3000/4000/5000
6000/8100/9140
89
3 1/2” REG, 4 1/2” REG,
140
11
3000/4000/5000
6000/8100/9140
10670
114
4 1/2” REG,
140
19
3000/4000/5000
6000/8100/9140
10670
114
4 1/2” REG,
Company Profile
Factory
Why choose us
Certifications
Exhibition
Packing and delivery
FAQ


1. Q锛欰re you manufacturery or trade company? A:We are manufacturer, has more than 10 years of professional production experience .Products including DTH Hammer and Bit銆丏rill Pipe Casing System銆乀ricone Bit銆乀op Hammer Drill Rod銆� Drill Bit銆乀apper Button Bit and Rod銆� Integral Drill Rod etc. 2.Q: Do you offer warranty on your products? A: Yes. For different products we offer different warranty that cover all manufacturing defects in materials and workmanship. The longest period of warranty is 6 months after shipping date. 3銆丵: How is your quality control? A: We have our own experienced quality control. There will be strict inspection and testing for every order before shipping out. 4.Q: How long is your delivery time? A: 1-5days for the products in stock锛� regular order delivery in 2-3weeks. 5.Q: After Services: A:(1) Our sales team will response for your question within 24 hours (Holidays included). (2) Technical Support will be available in any time. (3)Free replacement will provide once the failure confirmed caused by our product quality. 6.Q:Methods of Payment: A:We offer different payment terms, including T/T, D/A, D/P, L/C and O/A, etc. You can choose your preferred payment methods before we shipping the goods. 7Q: Do you offer OEM service? A:Yes, we can offer OEM service if you have regular requirement. 8Q: Where did you export ? A:Till 2023 we have exported to 60+ countries.
