Handheld Laser Welder Metal Fiber Laser Welding Equipment Manual Machine

Handheld Laser Welder Metal Fiber Laser Welding Equipment Manual Machine

$1,401.00 USD
$1,753.50 USD $1,401.00 USD
Sale Sold out
Shipping calculated at checkout.
Working Area


Mr. Nick

Jinan Rakoncnc Machinery Co., Ltd

Whatsapp:+86-15665837365
Email:export20@rakoncnc.com
https://www.rakoncnc.com


Handheld Laser Welder Metal Fiber Laser Welding Equipment Manual Machine


Product Description


●Perfect laser laser welding machine is composed of an integrated cabinet, fiber laser source, refrigerating water circulation system, laser control system and a hand-held laser welding head. Compared with traditional welding methods, the integrated design of laser welder not only reduces the difficulty of the welding operation but also greatly improves the efficiency and quality of welding. This makes the welding work easier, the welding speed faster, and the quality of the finished product is better.

●This laser welder is widely used in metal advertising characters welding, stainless steel engineering welding, sheet metal cabinet welding and welding of large sheet metal structures.





Product Features Of The laser welder


●Small area, flexible and convenient.The laser welder has integrated design, laser source,water tank, control section is integrated, covers a smaller area,low on the venue, with mobile pulleys, can adjust the station at any time according to site requirements, convenient and flexible.

●The welding quality is good,the welding is firm. Continuous laser mode, smooth transition, no fish scale, strong welding makes the laser welder no need for secondary polishing treatment, reduce manual and time cost.

●Flexible and convenient,freely welding.Handheld laser heads, light-weight and flexible, which makes the laser welding machine can coule be welded to any part of the work piece, small work piece size and spatial range limit, long-lasting work is not easy to fatigue.

●The light beam quality of the laser welder transmission welding is good,the solder joint is more uniform, and the melt point isbetter.

●LCD screen display, centralized button, simple operation.



NO

Description

Parameter

1

Model

RCW1000 / RCW1500 / RCW2000 / RCW3000

2

Laser Power

1000W / 1500W / 2000W / 3000W

3

Range of adjustable power

1-100%

4

Central wavelength

1064nm

5

Line length

Standard 10m, maximum support 20m

6

Way of working

Continuous/modulation

7

Speed range

0-120mm/s

8

Repeat precision

±0.01mm

9

Welding gap requirements

≤0.5mm

10

Cooling water

Industrial thermostatic water tank

11

Laser Type

BWT / JPT / Raycus / Reci / IPG / Max

12

Working humidity

<70% no condensation

13

Focal Spot Diameter

0.2-2mm

14

Welding depth

0.3 - 5mm

15

Pulse Frequency

0.1-100Hz

16

Voltage

220V/380V








Applicable Materials

This laser welder is suitable for welding many kinds of metals, including stainless steel, aluminum alloy, galvanized sheet.


Applicable industries

The laser welder is widely used in the welding of metal advertising characters, stainless steel engineering welding, sheet metal cabinet welding, and welding of large sheet metal structures.
